Guest On-Board Battery Charger - 6A - 1-Bank

Features:

• Microprocessor Controlled For Accurate Charging
• Isolated Outputs
• IP68 Waterproof
• Non Corroding Housing For Ultimate Reliability
• Footprint Same As Former Charge Pro Guest Chargers
• Intuitive Operation
• Completely Sealed, Epoxy Filled
• Charge Flooded, AGM Or Gel Batteries
• Universal Input 120/230V Input For Go-Anywhere Freedom
• Designed For Harsh Marine and Industrial Environments
• Outputs Can Be Put In Series Or Parallel For Higher Voltage Or Current
• Sense-Send Technology Senses The Power Needs Of Each Battery and Sends Correct Charge
• ConnectCharge Plug For Easy Assembly To Inlet With No Wiring
• Meet Global Industry Standards Including UL, CE, CSA, ABYC, California Efficiency Regulations (CEC)

• Dimensions: 3.5"L x 6.4"W x 2.3"D
• Input Voltage: 115 V 50/60 Hz AC
• Input Amps (Max): 2.0 Amps
• Input Voltage Range: 90-265A AC 50/60Hz
• Output Volts: 12V DC
• Charging Current: 6 Amp
• AC Cable Length: 6 ft. (1.8M)
• DC Cable Length: 4 ft. (1.2M)
• Banks: 1
• Protection Type: IP68 (Casing)
• Absorption Charge Voltage (Per Bank): 14.3 V +/- 0.20 V
• Float Charge Voltage (Per Bank): 13.3 V +/- 0.20 V
• Rechargeable Battery Type: Any 12 V Lead Acid Batteries (Flooded and AGM)
• Battery Charge Capacity (Based On 50% Drained Battery): Group 24 Through 31 (Up To 120 Amp-Hours)
